Insulated Tempered Glass Door

The insulated tempered glass door combines advanced thermal insulation with robust tempered glass construction for commercial refrigeration. This product delivers exceptional energy efficiency while maintaining crystal-clear product visibility, ideal for supermarkets and convenience stores.
Send Inquiry
Description

Double Insulated Glass Door


31

The insulated tempered glass door combines advanced thermal insulation with robust tempered glass construction for commercial refrigeration. This product delivers exceptional energy efficiency while maintaining crystal-clear product visibility, ideal for supermarkets and convenience stores.



Product Specifications





Item

Specification

Model

IG-01

Glass Thickness

4mm + 12A + 4mm Tempered Glass

Insulation Type

Double Glazed with Argon Gas

U-Value

≤ 1.8 W/m²·K

Max Door Size

1200mm (W) × 2400mm (H)

Frame Material

Aluminum Alloy / PVC

Hinge Type

Heavy-Duty Adjustable Hinge

Temp Range

-25°C ~ +10°C

Gasket

Magnetic EPDM Sealing



Product Advantage



1.Superior Thermal Insulation



Our insulated tempered glass door features double-glazed construction with argon gas filling, creating an effective thermal barrier that reduces heat transfer. It achieves a U-value of ≤ 1.8 W/m²·K, ensuring excellent energy conservation.

INSULATING GLASS001
INSULATING GLASS-2001

2.High-Strength Tempered Glass



Manufactured with fully tempered safety glass 4-5 times stronger than ordinary glass, our insulated tempered glass door provides exceptional impact resistance. In case of breakage, it shatters into small granular pieces for maximum safety in commercial environments.

3.Full Customization Services



We provide comprehensive customization for the triple insulated glass door, including custom sizes, shapes, logo silk screen printing, and various edge processing options like polishing, chamfering, and hole drilling.

CUSTOMIZATION001



Global Logistics Network





We provide comprehensive global logistics for our insulated tempered glass door products, including professional export packaging with foam protection and wooden crating. With extensive international shipping experience, we handle all CE certification documentation. Our MOQ starts at 100 units with flexible container loading options.



Application Scenarios





The insulated tempered glass door is widely used in supermarket display freezers, convenience store beverage coolers, commercial refrigeration cabinets, walk-in cooler display doors, and cold storage access doors.
